| Size: | |
|---|---|
| Net Weight(kgs): | |
| Color: | |
| Standard: | |
| Quantity: | |
● Faster Charging & Maximized Savings: The electric vehicle charger offers 7X higher speed than level 1 EV chargers, providing an impressive 37 miles of range in just one hour. The EV charger for home supports APP management and Wi-Fi connectivity, you can adjust the current intensity, schedule charging time, and monitor charging data in real-time. Setting a scheduled charging time during off-peak hours lowers electricity bills and saves you money!
● CSA Certified & NEMA Type 4: The EV car charger is CSA certified and meets UL safety standards(UL2594 standard). You can be confident in the safety and reliability of the fast charging station. The 48 amp EV charger is built with robust NEMA 4 waterproof protective housing, making it resilient to external influences. It comes with a high-quality 16ft premium cable, giving you peace of mind when charging in all weather conditions.
● Flexible Installation: All you need to do is set up a basic NEMA 14-50P outlet and connect the XZZ EV charger to it. We've also included installation instructions to offer you a detailed guide, ensuring you set up and use it correctly for a hassle-free installation experience.
● Universal Compatibility & Installation Recommended: The wall-mounted EV charger is compatible with all J1772 electric vehicle models. For optimal performance and safety, we recommend installing the level 2 ev charger 48 Amp on a circuit breaker rated at 50A or higher. Please consult a professional electrician for installation. In addition, You can contact customer service to get a Tesla adapter. (Adapter ASIN: B0CLLTWG2S) Note: Tesla EVs need to be equipped with a special adapter to be compatible.
● Smart Control & Easy Management: The 4.3-inch LCD screen displays the charging rate, time, voltage, and charged amount, so stay informed about your EV's charging progress and status. It also facilitates effortless device sharing and allows multiple users in your home to control it simultaneously.
| Place of Origin | Jiangsu, China |
| Interface Standard | Type2 |
| Output Current | AC |
| Output Power | 11kW |
| Input Voltage | 100 - 110v |
| Purpose | for retrofit/upgrade |
| Condition | New |
| Model Number | AC11000-HK-16 |
| Brand Name | XZZ |
| Power Supply | L1+L2+G |
| Color | Pearl White/Starry Black/Emerald Green |
| Leakage Current Protection | CCID 20 |
| Enclosure Rating | NEMA4 |
| Impact Protection | IK10 |
| Working Temperature | -30℃ ~+50℃ (-22 ℉ -122 ℉) |
| Certification Standard | UL/FCC/Energy Star |
| LED Indicator | Green/Yellow/Red |
| OCPP | OCPP 1.6 Json |
| Quantity (sets) | 1 - 10 | 11 - 300 | 301 - 1000 | > 1000 |
| Lead time (days) | 7 | 15 | 35 | To be negotiated |
Sample price: $190.00/set
Product Paramenters
| Datasheet | Model | AC11000-HK-16 |
| Input | Power Supply | L1+L2+G |
| Rated Voltage | 240VAC | |
| Max Current | 48A | |
| Frequency | 60Hz | |
| Wiring Type | NEMA 14-50P/NEMA 6-50P | |
| Output | Max Power | 11kW |
| Charging Outlet | SAE J1772 Compliant, Type 1 Plug | |
| Cable Length | 5m(20feet) | |
| User Interface | Housing Material | PC |
| PC LED Indicator | Green/Yellow/Red | |
| RFID Reader | Mifare ISO/IEC 14443A | |
| Start Mode | APP/Plug&Play/RFID | |
| Communication | Wi-Fi | Yes |
| Bluetooth | Yes | |
| OCPP | OCPP 1.6 Json | |
| Safety | Leakage Current Protection | CCID 20 |
| Enclosure Rating | NEMA4 | |
| Impact Protection | IK10 | |
| Electrical Protection | Over current protection, Ground protection, Surge protection, Over/Under voltage protection, Over temperature protection | |
| Certification Standard | UL/FCC/Energy Star | |
| Environment | Limited Warranty | 2 years |
| Installation | Wall-mount/Floor-mount | |
| Working Temperature | -30℃ ~+50℃ (-22 ℉ -122 ℉） | |
| Working Humidity | 5%~95% | |
| Work Altitude | <2000m(6561.7feet) | |
| Weight | Net Weight | 3.8kg/8.36lb |
| Gross Weight | 4.3kg/9.46lb | |
| Package | Package Dimension | 380*285*175mm/14.82*11.2*6.83in（L*W*H） |
| Product Dimension | 233*150*70mm/9.1*5.85*2.73in（H*W*D) |
FAQ
1.Q:How long is the delivery time of your solar power station products?
A:We can ship in 3 days if ship from oversea warehouse.
2.Q:What kind of certificates your EV charger products have?
A:solar generator power station products have acquired UN38.3, CE, FCC, UL and PSE certificates, which is able to satisfy most country’s importing requirements.
3.Q:Can you ship your EV charger products by sea or by air ?
A:We have long-term cooperated forwarders who are professional at battery shipment.
4.Q:Can I customize EV charger products?
A: Let me know the specific customization requirements and I will get back to you as soon as possible.
5.Q:How do you provide after-sales service?
A:We have overseas branches can provide repair and replacement.
6.Q:Can I get a EV charger sample?
A:Yes, please leave your contact information and our sales manager will contact you soon.
7.Q:who are we?
A: We are based in Guangdong, China, start from 2013,sell to North America(60.00%),Domestic Market(15.00%),Western Europe(10.00%),South America(8.00%),Oceania(3.00%),Africa(2.00%),Eastern Europe(2.00%). There are total about 301- 500 people in our office.
8.Q:how can we guarantee quality?
A:Always a pre-production sample before mass production;Always final Inspection before shipment;
9.Q:what can you buy from us?
A:Jump starter,Car Jump Starter,Portable Jump Starter,Power Station,Emergency Energy Storage
10.Q:why should you buy from us not from other suppliers?
A:Own200,000 square meters battery cell production industrial JEV charger 7 years experience for OEM and ODM Patent new battery cell technology and QDSP jump starter 30 people R&D team,all product are private mould 200,000pcs capacity per month
11.Q:what services can we provide?
A:Accepted Delivery Terms: FOB;Accepted Payment Currency:USD;Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;Language Spoken:English,Chinese,Spanish,JAPAN.
